• The hinge is suitable to be installed on doors and frames in wood and aluminium.
• The hinge can be fitted with door closing devices.
• CE certified - European Assessment Document 020001-01-0405
• Fireproof certified 45’ - UNI-EN 1634-1
• Material of casing: ZAMAK.
• Material of levers: ALUMINIUM.
• Aluminum caps available to conceal the screws.
• The hinge can be fitted right and left and grants the reversibility of the door, both on vertical and horizontal axis.
• Movement on 7 junction fulcrums equipped with bearing in plastic HT with high resistance and long life.
• Equipped with 3-way adjustments that can be settled by means of just one 3 mm hex-spanner.
• Compatible with millings of IN300 and IN305 hinges.
• Patented EP-B- 2719851.
